IGS-3032GC User’s Manual
38
RSTP Setting interface
The following table describes the labels in this screen.
Label Description
RSTP mode
You must enable or disable RSTP function before configuring
the related parameters.
Priority (0-61440)
A value used to identify the root bridge. The bridge with the
lowest value has the highest priority and is selected as the
root. If the value changes, You must reboot the switch. The
value must be multiple of 4096 according to the protocol
standard rule.
Max Age (6-40)
The number of seconds a bridge waits without receiving
Spanning-tree Protocol configuration messages before
attempting a reconfiguration. Enter a value between 6
through 40.
Hello Time (1-10)
The time that controls switch sends out the BPDU packet to
check RSTP current status. Enter a value between 1 through
10.
Forwarding Delay Time
The number of seconds a port waits before changing from its
