4.6 Backplane FAQs
Question#1
How many lanes are available on EB16?
Answer:
There are 192 Lanes Available
Question#2
There are two switches on the EB16. How many lanes are in-between these two or lanes allocated per switch?
Answer:
Total allocated 96 lanes on first Switch station 1 (From slot1 to slot6)
 PCIe switch (PLX) uses 16 lanes.
 Upstream Port use x16 lanes (Expansion slot)
96 lanes minus 16 from PCIe switch, minus 16 from Upstream port = 64 Lanes available/ ready to use.
From Slot1 to Slot6 = There are 64 lanes available combined
Slot 0 = x16
Slot 1 = x8
Slot 2 = x8
Slot 3 = x16
Slot 4 = x8
Slot 5 = x8
Slot 6 = x16,
------
Total = 64 Lanes
On the second switch station 2, there are also 96 available lanes (from slot7 to slot16)
 The PCIe switch itself uses 16 lanes.
96- 16 = 80 Available lanes ready to use
From slot7 to slot16 = There are 80 lanes available combined.
Slot 7 = x8
Slot 8 = x8
Slot 9 = x8
Slot 10 = x8
Slot 11 = x8
Slot 12 = x8
Slot 13 = x8
Slot 14 = x8
Slot 15 = x8
Slot 16 = x8
--------------
Total = 80 Lanes
