1 Introduction
1.1 General Specifications
OSS ExpressBox 16 Basic is a 16-Slot PCI Express® Expansion System. The expansion system consists of a PCIe® host interface card, an iPass
cable, a 4U rack-mount chassis containing a 16 Slot backplane and an expansion interface card, a standard or redundant power supply, and high
volume cooling fans.
ExpressBox 16 Basic
A choice of two backplane configurations:
 EB16-BX4: provides (16) x4 PCIe Gen 2 slots
 EB16-BX8: provides (2) x16 PCIe Gen 2 slots and (14) x8 PCIe
Gen 2 slots.
EB16 BASIC
1
Sixteen PCIe slots
2
Card Retainers
3
4 Cooling Fans (Replaceable)
4
Expansion Backplane
5
1 Power Supply Module
6
1 Expansion Interface Card
7
No Netburner
8
Single Power Switch
9
No LED Locator & Reset Button
10
1iPass Connectors to Host
11
16 Card slots
12
2 Thumb Screws
13
Two Front Handles
14
Front Power Button (On & OFF)
15
No Front LED Indicators
16
1 Link Cable
17
1 Host Interface card
18
No Express IO Manager / WEB GUI
1.2 Basic Features
 Easy “Plug and Play” installation
 PCI Express Gen 2 x16 or x8 interconnection
 All slots support full-length cards
 Status LEDs on backplane indicate active link, speed (Gen 1 or Gen 2), partial or complete lane training
 Automatic power-up control by computer
 Four hot-swappable cooling fans
 Multiple power supply options with auxiliary power connectors to support cards requiring more than 75 Watts
 Industrial 4U rack-mount enclosure
 Card retainers keep cards in place and are adjustable to fit any size card
 Chassis provides superior EMI control, vibration, shock and moisture resistance
