1.3 STATUS Specifications
Input Impedance Microphone > 2 k Ohms
Line Level Inputs > 12 k Ohms
All Outputs Impedance < 50 Ohms
Nominal Level (Balanced Outputs) +4 dBu
Nominal Level (Unbalanced Outputs) +0.5 dBu
Maximum Level Before Clipping (Balanced Outputs) +26 dBu
Maximum Level Before Clipping (Unbalanced Outputs) +21.5 dBu
Maximum Gain (Source to Track or Stereo Bus)
Microphone 74 dB
Line 48 dB
Tape 12 dB
Frequency Response (At Nominal Level, Filters and EQ Out)
Line to Track Bus Out 10 Hz - 20 kHz, +0/-.25 dB
Mic to Track Bus Out 20 Hz - 20 kHz, +0/-.25 dB
Tape to Stereo Bus Out 10 Hz - 20 kHz, +0/-.25 dB
Noise (20 Hz – 22 kHz, No Weighting, Input Termination 600Ω)
Mic (EIN 64dB Gain, 200 Ohms) -127 dBu
Track Buses (1 Path Assigned, Unity Gain) -86 dBu
Track Buses (16 Paths Assigned, Unity Gain) -72 dBu
Stereo Buses (1 Path Assigned, Unity Gain) -86 dBu
Stereo Buses (16 Paths Assigned, Unity Gain) -72 dBu
Distortion (THD+Noise, 20 Hz–20 kHz, at Nominal +4 dBu)
Line In to Track Out 0.05%
Tape In to Track Out 0.05%
Crosstalk Between Track Buses (No Panner) > 90 dB (1 kHz)
> 80 dB (20 Hz–20 kHz)
Between Stereo (L/R) Buses (Panner) > 70 dB (1 kHz)
> 65 dB (20 Hz–20 kHz)
Current Draw 24/24 Mainframe 245 VA Typical 415 VA Max.
32/32 Mainframe 326 VA Typical 645 VA Max.
40/40 Mainframe 408 VA Typical 645 VA Max.
48/48 Mainframe 490 VA Typical 645 VA Max.
Console Heat Dissipation 24/24 Mainframe 466 BTU/Hr. Typical 790 BTU/Hr. Max.
32/32 Mainframe 621 BTU/Hr. Typical 1230 BTU/Hr. Max.
40/40 Mainframe 777 BTU/Hr. Typical 1230 BTU/Hr. Max.
48/48 Mainframe 932 BTU/Hr. Typical 1230 BTU/Hr. Max.
Power Supply Heat Dissipation
24/24 Mainframe 508 BTU/Hr. Typical 860 BTU/Hr. Max.
32/32 Mainframe 677 BTU/Hr. Typical 1215 BTU/Hr. Max.
40/40 Mainframe 847 BTU/Hr. Typical 1215 BTU/Hr. Max.
48/48 Mainframe 1016 BTU/Hr. Typical 1215 BTU/Hr. Max.
Power Supply Fuses 110 VAC, 5 Volt Supply 3 Amp Slow Blow
110 VAC, Bipolar 16 Volt Supply 3 Amp Slow Blow
110 VAC, +48 Volt Supply 1/2 Amp Slow Blow
220 VAC, 5 Volt Supply 1.5 Amp Slow Blow
220 VAC, Bipolar 16 Volt Supply 1.5 Amp Slow Blow
220 VAC, +48 Volt Supply 1/4 Amp Slow Blow
1 - 4
August 1999
Section 1 Introduction STATUS 18R Operation and Maintenance Manual
