4 Delivery
4.1 Scope of supply
The power wheelchair is normally shipped fully assembled
and fitted to the personal requirements of the respective
user.
The scope of delivery includes:
• Fitted power wheelchair with main components
• Installed options
• Battery charger
• Instructions for Use (user)
4.2 Options
The standard model can be fitted to the user's personal
requirements through a large range of options.
A full list of the available modules and accessories is shown
on the order form and in the accessories catalogue.
To use options: see Page20 et. seq.
4.2.1 Model B600
The B600 power wheelchair with telescoping frame can be
equipped with up to four of the following power seat
options:
• Power seat height adjustment
• Power seat tilt available in three different versions (up to
20°, up to 30° and up to 45°)
• Power back angle adjustment up to 30°
• Electrically adjustable footrests with three program
mable versions (control of only left, only right or both
sides)
The wheelchair is controlled by an enAble50 control unit. An
optional LCD monitor is available for the control unit. It
enables special controls to be connected, among other
things.
For additional information on enabling/user specific adjust
ment of certain enAble50 control unit functions: see inside
front cover.
4.3 Storage
4.3.1 During daily use
The power wheelchair should always be protected against
external influences.
The control unit must be turned off.
4.3.2 In case of extended disuse
NOTICE
Deep discharge due to standby current
Risk of battery damage
► Remove the fuse if the wheelchair is not used for more
than 3 days.
INFORMATION
To remove the fuse, see section "Repair" > "Replacing a
defective fuse".
