60 | Ottobock B600
6.11.2 Attendant control
The power wheelchair can be equipped with an optional
separate control panel for attendant operation. The separate
control panel is height-adjustable and removable.
For the standard and contour seats, the attendant control is
located on the backrest cross tube. For the Recaro® seat,
the attendant control is located on the headrest.
Fig. 34 Attaching the attendant control
Functional overview
The attendant uses the attendant control to operate the driv
ing function and the power seat functions.
The module is connected in conjunction with the control
panel or as a separate input device.
Fig. 35 Attendant control
1 [On/Off] button 4 [Mode] button
2 Battery capacity (LED indic
ator)
5 Selected power seat func
tion (LED indicator)
3 Mode (LED indicator) 6 Joystick
[On/Off] Button
The button is used for switching the power wheelchair on,
activating the drive-away lock and switching the wheelchair
off.
Usage
