64 | Ottobock B600
Fig. 36 Push-button module
1 Available power functions
2 [Mode] button
3 Selected function (LED indicator)
4 [Selected function up/down] buttons (see information box)
5 Jack plugs for connecting Piko buttons
6.11.4 Special controls
Ottobock provides the option to equip the power wheelchair
with special controls with various input modules, e.g.:
• Mini/Midi joystick control
• Sip and puff control
• Chin control
• 5-button keyboard control
• Buddy and Piko buttons
Using and programming of a special control requires use of
an LCD monitor.
Detailed information on the available special controls and
their operation can be found in the "Special Controls"
instructions for use, article number 647G636=*.
Fig. 37 Example for a chin special control
Usage
