Otto Bock B600 - Power Seat Functions

Ottobock | 41B600
4) Turn the battery charger off when the charging process
is complete.
5) Disconnect the battery charger mains plug.
6) Disconnect the battery charger plug from the charging
receptacle.
7) Turn the power wheelchair control unit on.
→ The power wheelchair is ready to use.
Fig. 19 Charging/programming receptacle on the control pan
el
Fig. 20 Charging receptacle on power wheelchair
6.8 Power seat functions
The power wheelchair can be equipped with a range of
optional power seat functions.
6.8.1 Safety Instructions
WARNING
Driving with power seat options
Falling, tipping over due to user error
► Drive in street traffic only with the seat tilt and seat
height adjustments lowered and with a vertical back
rest.
Usage
