Unpacking
Outlaw Audio
4
Save all packing materials
Your Model 976 comes in a carton and packing ma-
terials designed speci cally to cushion it from shocks
and vibration commonly encountered in shipping.
We strongly suggest that you save the carton and
packing materials, and use them again if you move
or if the unit ever needs to be shipped back to us for
any reason.
To minimize the size of the carton in storage, you
may wish to atten it by carefully opening the top
and bottom aps and folding the carton at. Other
cardboard inserts may be stored in the same manner.
Packing materials that cannot be collapsed should
be saved along with the carton in a plastic bag.
Be careful when lifting and handling the Model 976.
The unit itself is not heavy, but the connectors on
the rear panel and the controls on the front panel
can be damaged by minor impacts.
Record your Model 976’s serial number and
date of purchase here. The serial number is
found on the back panel.
Serial Number
Date of Purchase
The contents of this manual are Copyright
© 2017 by Outlaw Audio, LLC., and may not
be duplicated or reproduced by any means,
whether physical, electronic or otherwise
without prior written consent from Outlaw
Audio, LLC.
Outlaw Audio and the Outlaw Audio logo are registered trade-
marks of Outlaw Audio, Inc. “Dolby,” “Pro Logic,” “TrueHD” and the
double-D symbol are trademarks of Dolby
Laboratories.
© Dolby Laboratories, Inc. All rights reserved.
“DTS” and “DTS Digital Surround” are trademarks of Digital
Theater Systems, Inc.
© Digital Theater Systems, Inc. All rights reserved.
Speci cations are those in e ect at the time of printing. Outlaw
Audio, LLC reserves the right to change speci cations or designs
at any time without notice, and without obligation to modity
existing units.
AUDIO IN
FM
75
AM 300
AM LOOP
Service
Normal
SOFTWARE UPGRADE
BLUETOOTH MODULE
COAX1
COAX2
L
RRS
RB
SUB
LS LB
C
7.1 CH IN
4
3
2
1
1
2
3
4
5
HDCP 2.2 HDCP 2.2
HDCP 2.2
HDCP 2.2
HDMI IN
HDMI OUT
7.2 CH OUT
Model 976
Outlaw Audio, LLC
Easton, MA USA
www.outlawaudio.com
Designed in the USA
Made in China
Serial No./No. De Series
ACCESSORY POWER
5VDC/1.0A MAX
TRIGGER OUT
IR I/O
OUT IN
HDCP 2.2
ARC
FR
FL RS LS RB LB C SUB1 SUB2
7.2 CH BALANCED OUT
model 976
INFO OSD ENTER
SOURCE
TUNER
PSetPSet
SET-UP MIC
STANDBY
TUNE
MODE
SURR
MODE
HDMI IN 6
VOLUME
6 IN 2 OUT
4Kx2K
