L-737-3-E
11
●
Separately mounted Transmitter
φ134
67
4-M6×8
230
127 103
100
64
7
50
125
60
188
60
30
60
30
344
233
61.7
171.5
46
CableentryG3/4
CableentryG3/4
Hold-down
hardware
(2×1)
Stanchion(2)
Fig. 4.2 Outline Dimensions of Transmitter
※ Hold-down hardware are supplied as standard accessories, but the customer is to furnish the stanchion.
Dimensions in millimeters
