■ Shipping Parameters
Given below is the explanation of parameters found in the parameter list attached to the product.
Continued on next page➡
No. Item Name Factory setting Setting
Transmitter information (Device Info)
1 Tag Tag No.
2 Descriptor Description
3 Message Message
4 Date Date of manufacture
5 Dev ID Device ID
6 Final asmbly num Serial No.
7 Snsr s/n Sensor serial No.
8 Snsr model Sensor model
9 Flange Flange rating
10 Snsr matl Sensor material
11 Hardware rev Hardware revision
Sensor information (Sensor Type)
12 Sensor type Sensor type
13 Mass flow USL Max. allowable rang
14 Mass flow LSL Min. allowable range
15 Temperature USL Max. allowable temperature range
16 Temperature LSL Min. allowable temperature range
Flow information (Flow)
17 Mass flow unit Instant mass flow rate unit
18 Vol flow unit Instant volume flow rate unit
19 Flow Direction Flow direction select
20 Damp Flow rate (mass) damping
21 Flow cutoff Flow rate (mass) cutoff
22 Vol flow coef Volume flow correction coefficient
Density information (Density)
23 Unit Density unit
24 Damp Density damping
25 Slug low limit Lower limit density, slug flow identification
26 Slug high limit Higher limit density, slug flow identification
27 Slug duration Slug flow identification duration
28 Density compensation Run reference temp. conversion setting
29 Standard temp Reference temperature
30 Expansion coef Expansion coefficient
31 Set density Run fixed density conversion setting
32 Density value Fixed density value
Temperature information (Temperature)
33 Unit Temperature unit
34 Damp Temperature damping
Analog output 1 information (Analog Output 1)
35 Assign Analog output 1 assignment
36 URV 20mA setting, analog output 1
37 LRV 4mA setting, analog output 1
38 Lowcut Low flow cutoff, analog output 1
39 Added damp Added damping, analog output 1
Analog output 2 information (Analog Output 2)
40 Assign Analog output 2 assignment
41 URV 20mA setting, analog output 2
42 LRV 4mA setting, analog output 2
43 Lowcut Low flow cutoff, analog output 2
44 Added damp Added damping, analog output 2
