Oval ALTImass CA004 - 13. PRODUCT CODE EXPLANATION

L-737-3-E
93
13. PRODUCT CODE EXPLANATION
Item
Product Code
Description
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱
Model
C A ALTI mass Type U
Nominal size
0 0 4 9/16″
Fluid category
L
Liquid
G Gas
Temperature category (※1)
1
Standard (below 130°C)
Pressure category
1 120MPa max.
3 120MPa with a rupture disk (Option)
Major parts material
X TPXM-19
Process connection
X High-press. Cone & Thread
Transmitter construction
1
Integrally mounted
2
Separately mounted
Power source
1 20 to 30VDC
2 85 to 264VAC (Safety rated 100 to 240VAC) 50/60Hz
Analog output
A
Output 1: Mass flow Output 2: Mass flow
C
Output 1: Mass flow Output 2: Temperature
E
Output 1: Mass flow Output 2: Volume flow (fixed density)
K
Output 1: Volume flow (fixed density) Output 2: Temperature
X
Non-output In the case of FOUNDATION fieldbus, PROFIBUS communication
Pulse output
A
Output 1: Mass flow
C
Output 1: Volume flow (fixed density)
D
Output 1: Mass flow Output 2: Mass flow
F
Output 1: Mass flow Output 2: Volume flow (fixed density)
H
Output 1: Volume flow (fixed density) Output 2: Volume flow (fixed density)
K
Output 1: Volume flow (fixed density) Output 2: Mass flow
X
Non-output In the case of FOUNDATION fieldbus, PROFIBUS communication
Pulse output type
0
Non-output In the case of FOUNDATION fieldbus, PROFIBUS communication
1
Open drain pulse (equivalent to open collector pulse) (standard)
2
Voltage pulse
Communication interface
1
HART communication
Bell202
2
FOUNDATION fieldbus H1 communication (※2)
ITR version 6
3
PROFIBUS PA communication (※2)
Profile version 3
4
Modbus communication RS-485 Modbus protocol
Explosionproof rating
0
Non-explosionproof
2 ATEX, IECEx
3 KCs (※3)
4 CSA
5 GOST (※3)
7 NEPSI (※3)
Explosionproof temperature class
0
Non-explosionproof
3
Sensor unit: Temp. class T3, separate transmitter only
4
Sensor unit: Temp. class T4
※1: Explosionproof specifications are restricted based on temperature class.
※2: When FOUNDATION fieldbus, PROFIBUS is selected for communication interface, product code categories of analog
output is "X" and pulse output is "X" (pulse output type:"0").
※3: "2" and "3" for the product code ⑯ are not available. (in preparation)
