Oval ALTImass CA004 - Page 95

L-737-3-E
95
Pulse output 1 information (Pulse Output 1)
45 Assign Pulse output 1 assignment
46 Freq factor Full scale frequency, pulse output 1
47 Rate factor Full scale flow rate, pulse output 1
48 Lowcut Low flow cutoff, pulse output 1
Pulse output 2 information (Pulse Output 2)
49 Assign Pulse output 2 assignment
50 Freq factor Full scale frequency, pulse output 2
51 Rate factor Full scale flow rate, pulse output 2
52 Lowcut Low flow cutoff, pulse output 2
Status input/output information (Status Input/Output)
53 Input function Function select, status input
54 Input mode Input mode select, status input
55 Output function Function select, status output
56 Output mode Output mode select, status input
High/low alarm information (H/L Alarm)
57 Assign High /low alarm assignment
58 H/L alarm type High/low alarm type select
59 High alarm point Higher limit alarm value
60 Low alarm point Lower limit alarm value
61 H/L alarm hys High/low alarm hysteresis value
Error information (Error Select)
62 Sensor failure
Output select in individual item
63 Transmitter failure
64 Calibration failure
65 Saturated alarm
66 Parameter failure
67 Transmitter alarm
68 Slug flow alarm
69 Calibration in progress
70 Fixed output
Output in an error information (Error Output)
71 Analog Analog output pattern in an error
72 Pulse Pulse output pattern in an error
Flow factor information (Flow Cal)
73 SK20 Meter factor of flow rate
74 SKM Meter error correction term
75 SKt Flow rate correction factor (Skt)
76 Cal temp Temperature during flow calibration
77 Cal freq Frequency during flow calibration
78 SKfa Flow correction factor (Skfa)
79 SKfb Flow correction factor (Skfb)
80 FKt Flow correction factor (Fkt)
Density factor information (Density Cal)
81 Dens (Water) Density during density calibration
82 Cal temp Temperature during density calibration
83 Cal freq Frequency during density calibration
84 Freq coef β Density correction coefficient
