Owon HSA1000 Series User Manual

6.Specification
74
Counter resolution
1 Hz，10 Hz，100 Hz，1 kHz
Counter uncertainty
±（frequency indication × frequency reference
accuracy + counter resolution）
Frequency Span
Span Range
0 Hz，100 Hz
to max frequency of instrument
Span Uncertainty
± span / (sweep points-1)
SSB Phase Noise
（20℃ to 30℃，fc=1GHz）
Carrier
Offset
10 kHz
< -106 dBc/Hz （Typical）
100 kHz
< -104 dBc/Hz（Typical）
1 MHz
< -115 dBc/Hz（Typical）
Residual frequency modulation 20℃ to 30℃，RBW=VBW= 1 kHz
Residual frequency
modulation
＜ 50 Hz（nominal）
Bandwidth
Resolution Bandwidth
（-3 dB）
1 Hz to 1 MHz，step by 1-3-5-10
RBW Accuracy
< 5%（nominal）

Owon HSA1000 Series Specifications

General

Brand	Owon
Model	HSA1000 Series
Category	Measuring Instruments
Language	English
