286
Automated gearbox
10.1 INTRODUCTION
General
The TraXon gearbox is a fully automated gearbox based on a mechanical gearbox
combined with an electropneumatic gear and clutch control system.
In contrast to conventional automatic gearboxes, the automated gearbox does not
show any tendency to creep when a gear is engaged.
Although the accelerator pedal has a kick-down section (full throttle), the automated
gearbox does not have an enforced gear-down shift function.
The automated gearbox always starts in fully automatic mode.
D005142
A
B
A Gearbox selector switch.
Rotary knob on automated gearbox to select forward, reverse and manoeuvr-
ing gear positions.
B Example of a steering column switch with an automated gearbox. Version de-
pended.
See section 'Right-hand steering column switch' in chapter 'Instruments and
controls'.
