Emergency repairs
1. When the vehicle is equipped with a manually shifted gearbox, move the gear
change lever to the neutral position.
2. Apply the park brake. Also see section 'Stopping procedure' in the chapter 'Driving'.
3. Stop the engine.
4. Remove all loose objects from the cabin to prevent damage.
5. Close the doors.
6. Put wheel chocks in front of and behind the wheels of the driven axle.
7. If the vehicle is equipped with side
skirts, the tap can be reached
through opening (1).
The pump mechanism (3) can be
operated after removing the cover
(2).
Press in the cover (2) at the front
and back to remove it from the side-
skirt.
8. Turn the tap fully to the right, against
the spring pressure, until locked in
position A. Use the jack rod.
9. Operate the pump so that the cabin tilts forward. The cabin locking mechanism
automatically releases. As soon as the cabin passes its natural point of balance, the
force of gravity gradually tilts the cabin further forward without additional pumping.
NOTE: The tilting of the cabin can be stopped at any time by
turning the tap to position B.
Tilting back
1. When the vehicle is equipped with a manually shifted gearbox, move the gear
change lever to the neutral position.
2. Turn the tap to position B.
3. Tilt the cabin back by operating the pump with the jack rod. When the cabin has
passed the centre of gravity it falls back in the catch. When the catch engages, the
cabin is automatically locked.
2
1
3
A
B
