339
Emergency repairs
Battery box with extra terminals
Terminals where the starter cables can be connected are found on the lower side of the
battery box or on the left side behind a cover.
Remove the cover (1) and connect the starter cable to the positive pole (+) first. Then
connect the starter cable to the negative pole (–).
To disconnect, release the negative pole (–) first, then the positive pole (+) and install
the cover.
D001657-2
2
1
D005081-2
2
1
D005163
1
2
DW63246305.book Page 339 Friday, March 22, 2019 4:54 PM
