82
Instruments and controls
Spring-loaded position:
Switch off daytime running lights.
When the engine is running and the lighting is not switched on, the
daytime running lights come on automatically. Apply the park brake and
turn the light switch to this position. Hold it in this position for a short while
to switch off the daytime running lights.
The yellow warning on the instrument panel indicates the function is
switched off.
Position 0: Lighting switched off.
Position 1: Marker lights on.
Position 2: Headlights and marker lights on.
The light switch must be in position 1 or 2.
Front fog lights
Pull out the light switch one step to switch on the front fog lights.
When the front fog lights are on, the warning indicator on the instrument
panel is visible.
Rear fog lights
Pull out the light switch one step further to switch on the rear fog lights
together with the front fog lights.
When the rear fog lights are on, both warning indicators on the
instrument panel are visible.
If no front fog lights are fitted, the switch can only be pulled to the second
step when the light switch is in position 2. Only the warning indicator for
the rear fog lights will be on.
2. Instrument panel (DIP-5)
3. Speedometer
Depending on the vehicle model, the speedometer has a single scale
division in km/h or a double scale division in km/h and mph.
DW63246305.book Page 82 Friday, March 22, 2019 4:54 PM
