The safety sensor that need mechanical maintenance are:
- turntable encoder
- extension sensor
Turntable encoder
check the two encoders on the turntable after desmounting the cover (Fig. 5.16).
The plastic gear must be connected securely to the sensor without show particular
plays or usury. Tight all the screws and clean it from dirt.
Fig.5.16
For the machine with the other type of turret (with the endless screw), check the tightness
of the encoder mou
nted on the rotation block like shows in Fig. 5.17.
Check the integrity of the linking shaft between the encoder and the turret system; if there
are deformations or cracks, do not use the equipment and contact Palazzani Industrie.
Fig. 5.17
