Palfinger MBB C 750 S Assembly Instructions

28
Installing lifting mechanism
Table 1: Tightening torques on the consoles
Type of tail lift Bolts/consoles Bolt type
Tightening
torque
C 500 SD
4 M14x1.5 190 Nm
C 500 SPLD/SPRD
C 750 SPL/SPR
C 750 S
C 500 LD
C 750 L
C 750 LX
C 750 LG
C 750 LD
C 750 ML (PRO) -
C 1000 ML (PRO)
C 750 SPLD/SPRD
6 M14x1.5 190 Nm
C 1000 S
C 1000 SPL/SPR
C 1000 LD
C 1000 L
C 1500 L
C 1500 ML PRO
C 1500 S - C 2000 S
10 M14x1.5 190 Nm
C 1500 LX - C 2000 LX
C 1500 SZ
C 2000 LZ
C 1500 SK - C 2000 SK
C 2000 L - C 2500 L
C 2000 LK
C 2000 LX PTG
C 2500 S
12
10
M14x1.5
M16x1.5
190 Nm
310 Nm
C 2500 SK
C 2500 SD
14 M14x1.5 190 Nm
C 3000 S
NOTE
Screws and nuts may only be used once. If these are loosened, use new screws
and nuts to ensure 100% clamping performance.
