∫ To display the Mode Information
Each time you set the DISP/MODE CHK switch from ON to CHK, the mode information display
switches in the following order:
Mode information display1 # Mode information display2 # Mode information display3 #
Normal
display
You can use convenient functions just by the easy operation of touching the screen.
1 Touch the LCD monitor in the recording
screen.
≥ The operation icons are displayed.
2 Touch an operation icon.
≥ The following function is available. Refer to the respective
pages for the operation.
* It is not displayed when [i.Zoom] is set to [OFF].
≥ If you touch the screen while an operation icon is being displayed or do not touch the icon for a
certain period, it will disappear. To display again, touch the screen.
Mode information display1: Displays the list of functions assigned to the USER buttons
(USER1 to 8).
Mode information display2: Displays the settings assigned to the GAIN switch ([GAIN L]/
[GAIN M]/[GAIN H]), White Balance modes assigned to the WHITE
BAL switch ([WHITE BAL A]/[WHITE BAL B]/[WHITE BAL PRST]),
and the [SUB REC BUTTON] and [SUB ZOOM] settings.
Mode information display3: Displays the settings for [OUTPUT SEL], [OUTPUT BITS],
[SDI REMOTE], [REMOTE REC LINK], [HDMI TC OUTPUT] and
[CAMERA NUMBER].
Recording
Using Operation Icons
, etc. Customize Scene (l 130)
, etc. USER Button Icon (l 74)
/ i.Zoom Button Icon (l 41)*
SCN1 SCN2 SCN3 SCN4 SCN5 SCN6
MENU
ATW
DRS
PRE-REC
