Panasonic DMR-ES35VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R45001 ERJ3GEY0R00V 1/10W 0 1
R45002 ERJ3GEY0R00V 1/10W 0 1
R45008 ERJ3GEYJ102V 1/10W 1K 1
R45009 ERJ3GEYJ102V 1/10W 1K 1
R45014 D0GB473JA041 1/10W 47K 1
R45015 D0GB473JA041 1/10W 47K 1
R45016 D0GB221JA041 1/10W 220 1
T11101 G4D2A0000267 TRANSFORMER 1
T11301 G4D2A0000268 TRANSFORMER 1
VA11101 ERZVA5V471 SURGE ABSORBER 1
W302 ERJ3GEY0R00V 1/10W 0 1
W303 ERJ3GEY0R00V 1/10W 0 1
W304 ERJ3GEY0R00V 1/10W 0 1
W305 ERJ3GEY0R00V 1/10W 0 1
W306 ERJ6GEY0R00V 1/8W 0 1
W307 ERJ6GEY0R00V 1/8W 0 1
W308 ERJ6GEY0R00V 1/8W 0 1
W309 ERJ3GEY0R00V 1/10W 0 1
W310 ERJ3GEY0R00V 1/10W 0 1
W311 ERJ6GEY0R00V 1/8W 0 1
W312 ERJ6GEY0R00V 1/8W 0 1
W313 ERJ6GEY0R00V 1/8W 0 1
W314 ERJ3GEY0R00V 1/10W 0 1
W315 ERJ6GEY0R00V 1/8W 0 1
W316 ERJ6GEY0R00V 1/8W 0 1
W317 ERJ6GEY0R00V 1/8W 0 1
W320 ERJ6GEY0R00V 1/8W 0 1
W321 ERJ3GEY0R00V 1/10W 0 1
ZA11101 EYF52BCY FUSE HOLDER 1
ZA11102 EYF52BCY FUSE HOLDER 1
## VEPV0057A FRONT JACK P.C.B. (RTL)
C3801 F1H1H103A220 50V 0.01U 1
C3802 F1H1C104A008 16V 0.1U 1
JK3802 K1AY106A0002 JACK,S VIDEO IN 1
JK4600 K2HA307A0009 JACK,IN 2 1
LB3301 ERJ3GEY0R00V 1/10W 0 1
LB3302 ERJ3GEY0R00V 1/10W 0 1
LB3303 ERJ3GEY0R00V 1/10W 0 1
PP4801 K1KA10B00196 CONNECTOR(10P) 1
R3801 ERJ3GEYJ750V 1/10W 75 1
R3802 ERJ3GEYJ750V 1/10W 75 1
R3803 ERJ3GEYJ750V 1/10W 75 1
R3804 ERJ3GEYJ102V 1/10W 1K 1
R4305 ERJ3GEY0R00V 1/10W 0 1
R4306 ERJ3GEY0R00V 1/10W 0 1
R7801 D0GB392JA007 1/10W 3.9K 1
R7802 D0GB392JA007 1/10W 3.9K 1
R7803 D0GB392JA007 1/10W 3.9K 1
R7804 D0GB272JA007 1/10W 2.7K 1
R7805 D0GB272JA007 1/10W 2.7K 1
R7806 ERJ3GEYJ822V 1/10W 8.2K 1
S7801 EVQ11G07K SWITCH,CH-DOWN 1
S7802 EVQ11G07K SWITCH,REW 1
S7803 EVQ11G07K SWITCH,CH-UP 1
S7806 EVQ11G07K SWITCH,POWER 1
S7810 EVQ11G07K SWITCH,FF 1
S7813 EVQ11G07K SWITCH,EJECT 1
W550 ERJ3GEY0R00V 1/10W 0 1
W551 ERJ3GEY0R00V 1/10W 0 1
## VEPV0058A FRONT P.C.B. (RTL)
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C7701 F1H1C104A008 16V 0.1U 1
D7702 B3ADA0000183 DIODE 1
D7703 B3ACA0000252 LED 1
D7706 B3AAA0000752 DIODE 1
IC7701 B3RAD0000122 IR RECEIVER 1
PP7702 K1KA12B00129 CONNECTOR(12P) 1
Q7702 2SD0601A0L TRANSISTOR 1
Q7703 2SD0601A0L TRANSISTOR 1
Q7706 2SD0601A0L TRANSISTOR 1
R7703 D0GB152JA007 1/10W 1.5K 1
R7704 D0GB152JA007 1/10W 1.5K 1
R7705 D0GB391JA041 1/10W 390K 1
R7706 D0GB391JA041 1/10W 390K 1
R7707 D0GB222JA041 1/10W 2.2K 1
R7710 D0GB221JA041 1/10W 220 1
R7714 D0GB152JA007 1/10W 1.5K 1
R7715 ERJ3GEYJ271V 1/10W 270 1
R7716 D0GB104JA007 1/10W 100K 1
R7718 D0GB104JA007 1/10W 100K 1
R7719 D0GB104JA007 1/10W 100K 1
S7702 EVQ11G07K SWITCH,DVD 1
S7703 EVQ11G07K SWITCH,REC 1
S7704 EVQ11G07K SWITCH,PLAY 1
S7705 EVQ11G07K SWITCH,STOP 1
S7706 EVQ11G07K SWITCH,SELECT 1
S7707 EVQ11G07K SWITCH,OPEN/CLOSE 1
S7711 EVQ11G07K SWITCH,VHS 1
W444 ERJ3GEY0R00V 1/10W 0 1
W445 ERJ3GEY0R00V 1/10W 0 1
W446 ERJ3GEY0R00V 1/10W 0 1
W447 ERJ3GEY0R00V 1/10W 0 1
## CASING/ACCESSORY/P
ACKING
1 VEP001P1C SD-DV INPUT P.C.B. 1 (RTL)
2 VEPV0054BT MAIN P.C.B. 1 (RTL)
4 VEPV0057A FRONT JACK P.C.B. 1 (RTL)
5 VEPV0058A FRONT P.C.B. 1 (RTL)
6 RFKBV0061A DVD IF P.C.B. 1 (RTL)
7 K4ZZZZ000008 GASKET 1
8 L6FALCCE0016 FAN MOTOR 1
9 RHD30111-3 SCREW 19
10 RHD30113 SCREW 4
11 RHDC0023 SCREW 3
13 RMQ1513 HEAT TRANSFER
SHEET
1
14 RMX0354 MECHA SPACER(F) 1
15 RMX0355 MECHA SPACER(R) 1
16 RMZ0776 CELL COVER 1
17 RMZ0791 BARRIER 1
18 RMZ0839-1 BARRIER 1
19 RKA0178-X LEG 2
20 VKA0382 LEG CUSHION 2
21 RMC0672 PLATE SPRING 1
22 RMY0357 HEAT SINK 1
23 RYPV0149-S FRONT PANEL ASS’Y 1 ES35VP
23 RYPV0150-S FRONT PANEL ASS’Y 1 ES35VPC
23-1 RGUV0148-S DUB BUTTON 1
23-2 RHD26045-L SCREW 10
23-3 RKWV0063-Q1 FR WINDOW 1
23-4 RKWV0061-Q1 FRONT WINDOW 1
23-5 RGKV0143-H1 SD SLOT 1
23-6 RKFV0058-S1 SD DOOR 1
23-7 RMB0821-1 SD SPRING 1
117
DMR-ES35VP / DMR-ES35VPC
