Panasonic DMR-ES35VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
23-8 RKFV0056-S1 TRAY DOOR 1
23-9 RKFV0057-S BLINDER PANEL 1
23-10 RMB0857 TRAY DOOR SPRING 1
23-11 RMRV0039 TRAY DOOR STOPPER 1
23-12 VMB2521 BLINDER SPRING 1
23-13 RGUV0146-S EJECT BUTTON 1
23-14 RGUV0147-S OPEN BUTTON 1
24 VGQ8142 RIVET 1
25 RHD30119-S SCREW 11
26 VHD1770 SCREW 1
27 VJF0036 NYLON RIVET 2
28 RWJV0047 FFC(20P) 1
30 RWJV0033 FFC(7P) 1
31 RWJV0034 FFC(6P) 1
32 VKC0295 PCB HOLDER 2
34 XTV26+5FFJ SCREW 1
35 XTW3+10PN SCREW 1
38 RKM0588-S TOP CASE 1
39 XSN3+4FJ SCREW 1
40 RGRV0050B-A3 REAR PANEL 1 ES35VP
40 RGRV0050B-B3 REAR PANEL 1 ES35VPC
41 RFKNES35VP RAM/DIGITAL P.C.B.
MODULE
1 ES35VP(RTL)
41 RFKNES35VPC RAM/DIGITAL P.C.B.
MODULE
1 ES35VPC(RTL)
45 RMAV0036 DIGITAL ANGLE 1
46 RMBV0047 EARTH SPRING 1
101 VEG1697KIT RDD CYLINDER ASS’Y 1
101-1 VMD5464 FPC HOLDER 1
102 VEM0800T CAPSTAN MOTOR 1
103 L1AZ00000004 FE HEAD ASS’Y 1
104 VDB1431 TENSION ARM BOSH 1
105 VDG1686 INTERMEDIATE GEAR 1
106 VDG1685 MAIN CAM GEAR 1
107 VDG1512-1 IDLER GEAR 2
108 VDG1514-3 CHANGE GEAR 1
109 VDR0372A REEL TABLE 2
110 VDV0391-2 CAPSTAN BELT 1
111 VEM0797 LOADING MOTOR 1
112 VMB3550A CHANGING GEAR
SPRING
1
113 VMD4987 WORM SHAFT HOLDER 1
114 VMD5466 OPENER PIECE 1
115 VMD4253-1 LED PRISM 1
116 VML3934 MAIN LEVER 1
117 VML3933 PINCH CHARGE ARM 1
118 VML3632 IDLER ARM 1
119 VMX3092 P4 CAP 1
120 VXA7105-3 S SHAFT HOLDER 1
121 VXA7106-3 T SHAFT HOLDER 1
122 L1AE00000044 AC HEAD ASS’Y 1
122-1 VHD1066-2 SCREW 2
122-2 VHD1185 SCREW 1
124 VXL3107 S LOADING ARM 1
125 VXL3108 T LOADING ARM 1
126 VXL3109-7 PINCH ARM UNIT 1
127 VXL3110 P5 ARM 1
128 VXL3111-1 TENSION ARM 1
129 VXL3252 S BRAKE ARM 1
130 VXL3343 T BRAKE ARM 1
130-1 VMB3548-2A T BRAKE SPRING 1
131 VXL3124-2 CHANGING LEVER
UNIT
1
132 VXP2133-2 CENTER CLUTH UNIT 1
133 VXP2168 TORQUE CLUTCH 1
134 VMA0L25 TOP PLATE 1
135 VMD5468 SIDE PLATE(L) 1
136 VMD5469 SIDE PLATE(R) 1
137 VXA8265 CASSETTE HOLDER
UNIT
1
138 VXL3160 MAIN SHAFT 1
139 VXA8323 SECTOR GEAR 1
141 VML3706-3 OPENER LEVER 1
142 VHD1044-1 SCREW 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
143 XYN3+C4FJ SCREW 1
144 XTN26+7JFJ SCREW 3
145 XTV26+5FFJ SCREW 2
146 XTV26+8FFJ SCREW 2
148 VHD1117-1 SCREW 3
149 VMX2208 WASHER 1
150 VMX3114 WASHER 1
151 VMX2699 WASHER 1
152 VMX3196 WASHER 1
A1 EUR7659Y70 REMOTE CONTROL
ASS’Y
1
A1-1 UR76EC5903A BATTERY COVER 1
A2 VFA0461 AC CORD 1
A3 K2KA6BA00003 AV CORD 1
A4 K2KZ2BA00001 RF COAXIAL CABLE 1
A5 VPK2737 ACCESSORY CASE 1
A6 RQTV0134-2 OPERATING
INSTRUCTIONS
1 (IA)
A6 RQTV0135 OPERATING
INSTRUCTIONS
1 ES35VPC(IB)
A7 RQCAV0007 SET-UP GUIDE 1
A8 RPFX0042-2 VINYL BAG(F.B) 1
PC1 RPG7876-1 PACKING CASE 1 ES35VP
PC1 RPG7877-1 PACKING CASE 1 ES35VPC
PC2 RPN1860 CUSHION 1
PC3 VPF1122-1 POLYETHYLENE BAG 1
118
DMR-ES35VP / DMR-ES35VPC
