Panasonic FP-I4C User Manual

4.3 Mechanical installation
4.3.2 Attachment to DIN rails
The FP-I4C unit enables a one-touch attachment to DIN rails.
1. Fit the upper hook of the FP-I4C onto the DIN rail.
(2)
(1)
(1) Mounting panel
(2) DIN rail
2. Without moving the upper hook, press on the lower hook to fit the FP-I4C into position.
(2)
(1)
(1) Mounting panel
(2) DIN rail
4.3.3 Removal from a DIN Rail
You can easily remove the FP-I4C from a DIN rail as described below.
1. Insert a slotted screwdriver into the DIN rail attachment lever.
2. Pull the attachment lever downwards.
FP-I4C 23
