12.1.4 I/O Allocation of FP-X0 Control Unit
The I/O allocation of the FP-X0 control unit is fixed.
I/O numbers
Type of control unit
Number of allocation
I/O number
FP-X0 C14R control unit
Input (8 points)
X0 to X7
Output (6 points)
Y0 to Y5
FP-X0 L30R control unit
Input (16 points) X0 to XF
Output (14 points)
Y0 to YD
FP-X0 L40R control unit
FP-X0 L40MR control unit
Input (24 points)
X0 to XF
X10 to X17
Output (16 points)
Y0 to YF
FP-X0 L60R control unit
FP-X0 L60MR control unit
Input (32 points)
X0 to XF
X10 to X1F
Output (28 points)
Y0 to YD
Y10 to Y1D
