Panasonic FP-X0 L30R - Page 258

Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
F94
P94
16-bit data distribute
DIST
PDIST
S, n, D
Each of the digits of the data of “S” are
stored in (distributed to) the least
significant digits of the areas beginning
at “D”.
7
F95
P95
Character→ ASCII
code
ASC
PASC
S, D
Twelve characters of the character
constants of “S” are converted to ASCII
code and stored in “D” to “D+5”.
15
F96
P96
16-bit table data
search
SRC
PSRC
S1, S2,
S3
The data of “S1” is searched for in the
areas in the range “S2” to “S3” and the
result is stored in DT9037 and DT9038
7
F97
P97
32-bit table data
search
DSRC
PDSRC
S1, S2,
S3
The data of (S1+1, S1) is searched
for in the 32-bit data designated by
“S3”, beginning from “S2”, and the
result if stored in DT90037 and
DT90038.
11
Data shift instructions
F98
P98
Data table shift-out
and compress
CMPR
PCMPR
D1, D2,
D3
Transfer “D2” to “D3”. Any parts of the
data between “D1” and “D2” that are 0
are compressed, and shifted in order
toward “D2”.
7
F99
P99
Data table shift-in
and compress
CMPW
PCMPW
S, D1,
D2
Transfer “S” to “D1”. Any parts of the
data between “D1” and “D2” that are 0
are compressed, and shifted in order
toward “D2”.
7
F100
P100
Right shift of multiple
bits (n bits) in a 16-bit
data
SHR
PSHR
D, n
Shifts the “n” bits of “D” to the right.
5
F101
P101
Left shift of multiple
bits (n bits) in a 16-bit
data
SHL
PSHL
D, n
Shifts the “n” bits of “D” to the left.
5
F102
P102
Right shift of n bits in
a 32-bit data
DSHR
PDSHR
D, n
Shifts the “n” bits of the 32-bit data
area specified by (D+1, D) to the right.
5
F103
P103
Left shift of n bits in
a 32-bit data
DSHL
PDSHL
D, n
Shifts the “n” bits of the 32-bit data
area specified by (D+1, D) to the left.
5
F105
P105
Right shift of one
hexadecimal digit (4-
bit)
BSR
PBSR
D
Shifts the one digit of data of “D” to the
right.
3
F106
P106
Left shift of one
hexadecimal digit (4-
bit)
BSL
PBSL
D
Shifts the one digit of data of “D” to the
left. 3
F108
P108
Right shift of multiple
bits (n bits)
BITR
PBITR
D1, D2,
n
Shifts the “n” bits of data range by
“D1” and “D2” to the right.
7
F109
P109
Left shift of multiple
bits (n bits)
BITL
PBITL
D1, D2,
n
Shifts the “n” bits of data range by
“D1” and “D2” to the left.
7
F110
P110
Right shift of one
word (16-bit)
WSHR
PWSHR
D1, D2
Shifts the one word of the areas by
“D1” and “D2” to the right.
5
F111
P111
Left shift of one word
(16-bit)
WSHL
PWSHL
D1, D2 Shifts the one word of the areas by
“D1” and “D2” to the left.
5
F112
P112
Right shift of one
hexadecimal digit (4-
bit)
WBSR
PWBSR
D1, D2 Shifts the one digit of the areas by “D1”
and “D2” to the right.
5
F113
P113
Left shift of one
hexadecimal digit (4-
bit)
WBSL
PWBSL
D1, D2 Shifts the one digit of the areas by “D1”
and “D2” to the left.
5
: Available, : Not available, : Not available partially
