Panasonic FP-X0 L30R User Manual

Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
Time series processing instruction
F355 PID processing PID S PID processing is performed
depending on the control value
(mode and parameter) specified
by (S to S+2) and (S+4 to S+10),
and the result is stored in the
(S+3).
4
*1
F356 Easy PID
EZPID S1, S2,
S3, S4
Temperature control (PID) can be
easily performed using the image
of a temperature controller.
10
*2 *2
Compare instructions
F373
P373
16-bit data
revision
detection
DTR
PDTR
S, D If the data in the 16-bit area
specified by “S” has changed
since the previous execution,
internal relay R9009 (carry flag)
will turn on. “D” is used to store
the data of the previous execution.
6
F374
P374
32-bit data
revision
detection
DDTR
PDDTR
S, D If the data in the 32-bit area
specified by (S+1, S) has changed
since the previous execution,
internal relay R9009 (carry flag)
will turn on. (D+1, D) is used to
store the data of the previous
execution.
6
Index register bank processing instructions
F410
P410
Setting the
index register
bank number
SETB
PSETB
n Index register (I0 to ID) bank
number change over.
4
F411
P411
Changing the
index register
bank number
CHGB
PCHGB
n Index register (I0 to ID) bank
number change over with
remembering preceding bank
number.
4
F412
P412
Restoring the
index register
bank number
POPB
PPOPB
- Changes index register (I0 to ID)
bank number back to the bank
before F411 (CHGB)/P411
(PCHGB) instruction.
2
File register bank processing instructions
F414
P414
Setting the file
register bank
number
SBFL
PSBFL
n File register bank number change
over.
4
*3
F415
P415
Changing the
file register
bank number
CBFL
PCBFL
n File register bank number change
over with remembering preceding
bank number.
4
*3
F416
P416
Restoring the
file register
bank number
PBFL
PPBFL
- Changes file register bank number
back to the bank before F415
(CBFL)/P415 (PCBFL) instruction.
2
*3
: Available, : Not available, : Not available partially
*1) This instruction is available for FP0 (V2.1 or later) only.
*2) This instruction is available for FP-X V.1.20 or later, and FPΣ 32k type.
