14.3.6. PSTN Line
Address Default Name Type Description
0F00 03 UserCfg-1.Mode D User configuration (MMI) - mode settings 1.
Bit
0 : "R" mode, 0=earth break, 1=loop break
2..1: Dial mode, 00:pulse, 01:DTMF
3..7: Reserved
0F01 0D UserCfg-2.Mode D User configuration (MMI) - mode settings 2.
Bit
0..1: short "R" key time selection
00= short, 01=long, 10=extra-long
2..3: long "R" key time selection
00= short, 01=long, 10=extra-long,
11=undef (uses same time as specified for short R key)
4..7: Reserved
Defaults to 0000 1101
0F02 10 UserCfg.RPauseTime D User configuration (MMI) - "R"-pause. If disabled, normal
dial pause (DialPauseTime) is used.
Bit 7..0 : "R" pause time, zero value allowed
Unit : 50 ms, defaults to 800 ms.
0F03 03 UserCfg.DialPauseTime D User configuration (MMI) - dial pause.
Bit 3-0 : dial pause in 1 sec units , zero not allowed.
Bit 7-4 : unused
Defaults to 3 seconds
0F04 0F Cfg-1 D PSTN line configuration 1 (factory settings)
Bit
0: EarthBreakEnable , Earth break 1=enable 0=disable
1:LoopBreakEnable, Loop break 1=enable,0=disable
2:PulseDialEnable, Pulse dial 1=enable 0=disable
3:RPauseEnable, usage of "R" pause 1=enable, 0=disable
4:PulseType,0=normal puls-type
1=(’0’=1 pils,..’9’=10 puls’s).
5: InterDigitLowImp. controls interdigit impedance.
1: keep low-impedance during interdigit pause
0: normal impedance during interdigit pause
6: LowImpLineSeizure. Special low-imp line seizure
(Australian) , 1=enable , 0=disable
7: TwoLines. line config 0=one line, 1=two lines Defaults to
0000 0111B.
0F05 15 Cfg-2 PSTN line configuration 2 (factory settings)
Bit
0: Meter-pulse, 1=enable, 0=disable
1: DialToneMode, dial tone detection 1=enable 0=disable
2: BusyToneMode. busy tone detection 1=enable 0=disable
3: CurrentLimiterMode, 1=enable, 0=disable
4: RingToneMode. Ring tone detection 1=enable 0=disable
5: HookRelayEnable, 1=enable, 0=disable (if same port is
used for earth-control EarthBreakEnable and
HookRelayEnable cannot both be set to 1).
6..7: not used
Defaults to 0001 0101B.
0F06 28 MakeTime D Pulse make time.
Unit : 1 ms. defaults to 40 ms.
0F07 3C BreakTime D Pulse break time
Unit : 1 ms, defaults to 60 ms.
0F08 64 DtmfTime D DTMF tone pulse time.
Unit : 1 ms, defaults to 100 ms.
0F09 0A InterDigitDtmfTime D Inter-digit time in DTMF mode.
Unit : 10 ms , defaults to 100ms.
0F0A 4A InterDigitPulseTime D Inter-digit time in Pulse mode.
Unit : 10 ms, defaults to 740 ms.
0F0B 08 CalibBreakTime[0] D Calibrated loop-break time for short break
Unit : 10 ms, defaults to 80 ms.
0F0C 14 CalibBreakTime[1] D Calibrated loop-break time for long break
Unit : 10 ms, defaults to 200 ms.
0F0D 46 CalibBreakTime[2] D Calibrated loop-break time for extra-long break
Unit : 10 ms, defaults to 700 ms.
0F0E 28 CalibBreakTime[3] D Calibrated earth-break time for short break
Unit : 10 ms, defaults to 400 ms.
0F0F 82 CalibBreakTime[4] D Calibrated earth-break time for long break
Unit : 10 ms, defaults to 1300 ms.
0F10 82 CalibBreakTime[5] D Calibrated earth-break time for extra-long break
Unit : 10 ms, defaults to 1300 ms.
0F11 FF LineSeizureEndTime D Line seizure end-time - time after hook-on. Meter-pulse
detection continues during this period of time. 00h or FFh
means 10 ms.
Unit : 10 ms, defaults to 10 ms.
