Panasonic Lumix DC-S1 User Manual

6. Focus/Zoom
104
[225-Area]
The camera selects the most optimal AF
area to focus from 225 areas. When
multiple AF areas are selected, all selected
AF areas will be brought into focus. When
the focus mode is set to [AFC], ensuring
that the subject stays within the 225 areas
during recording will ensure the subject
stays in focus.

Specify the [AFC] Start Point
When the focus mode is set to [AFC], you can specify at which area to start
[AFC].
1
Set the focus mode to [AFC]. (l 91)
2
Set [AFC Start Point (225-Area)] to [ON].
0
¨ [ ] ¨ [ ] ¨ [AFC Start Point (225-Area)] ¨ [ON]
3
Press [ ] to display the AF mode selection screen.
4
Select [ ] and then press 4.
0
After performing Steps 1 and 2, the icon changes from [ ] to [ ].
5
Press 3421 to move the position of the AF area.
0
Positions can be moved to the diagonal directions using the joystick.
0 You can also move the AF area by touching.
0 To return the position back to the center, press [DISP.].
6
Press .

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
