Panasonic Lumix DC-S1 User Manual

1. Introduction
29
Displaying Viewfinder/Monitor
At the time of purchase, the viewfinder/monitor displays the following
icons.
For information about the icons other than those described here, refer to
page 448.
Viewfinder Monitor
999
ISO 100 F 4.060
L
FINE
AFSAFS
8 9 1011 12 13 14 15 16 17
1 2 43 5 6 7
999ISO100F4.060
±
0
AFSAFS
L
FINE
1
Photo Style (l 199)
2
Level gauge (l 339)
3
Picture quality (l 85)/
Picture size (l 83)
4
AF area (l 112)
5
Focus mode (l 91, 117)
6
AF mode (l 98)
7
Stabilizer (l 172)
8
Focus (lit green) (l 59)/Recording
state (lit red) (l 211, 230)
9
Recording mode (l 61)
10
Metering mode (l 178)
11
Shutter speed (l 59)
12
Aperture value (l 59)
13
Exposure compensation value
(l 189)/Manual Exposure Assist
(l 186)
14
ISO sensitivity (l 192)
15
Card slot (l 46)/Double card slot
function (l 87)
16
Number of recordable pictures
(l 482)/Number of pictures that can
be taken continuously (l 128)/
Available recording time (l 483)
17
Battery indication (l 42)
0 Press [ ] to switch between display/hide of the level gauge.

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
