Panasonic Lumix DC-S1 User Manual

216
10. Flash
If you attach the Flash (DMW-FL580L/DMW-FL360L/DMW-FL200L:
optional) to the hot shoe, you can record using the flash.
You can also use a commercially available external flash by connecting a
commercially available synchro cable to the flash synchro socket.
Furthermore, by attaching a compatible external flash to the camera, you
can wirelessly control external flashes placed in positions away from the
camera.
Removing the Hot Shoe Cover
Before attaching the Flash (optional), remove the hot shoe cover.
Refer to the operating instructions for the Flash for details about how to
attach it.
Remove the hot shoe cover by
pulling it in the direction indicated
by arrow 2 while pressing it in the
direction indicated by arrow 1.
Using an External Flash (Optional)
0 Before use, remove the lens hood to prevent vignetting.
0 Flash recording is not possible when the following functions are being used:
– Video recording/[6K/4K PHOTO]/[Post-Focus]
– [ELEC.]/[Silent Mode]/[High Resolution Mode]
– [Filter Settings]



Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
