Panasonic Lumix DC-S1 User Manual

2. Getting Started
46
You can use an XQD card and SD card with this camera. (l 22)
1
Open the card door.
≥Slide the card door in the direction
of the arrow while pushing down the
card door lock lever.
2
Insert the cards.
A Card slot 1: XQD card
B Card slot 2: SD card
≥Match the orientation of the cards
as shown in the figure and then
insert them firmly until they click.
0
Do not touch the SD card connection
contacts C.
3
Close the card door.
≥Close the card door and slide it
firmly in the direction of the arrow
until it clicks.
0
The cards are displayed on the status
LCD.
Inserting Cards (Optional)
0 You can set the way to record to card slots 1 and 2.
[] ¨ [ ] ¨ [Double Card Slot Function] (l 87)








Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
