Panasonic Lumix DC-S1 User Manual

13. Camera Customization
280
Register Functions to the Fn Buttons
1
Select [Fn Button Set].
≥ ¨ [ ] ¨ [ ] ¨ [Fn Button
Set] ¨ [Setting in REC mode]/
[Setting in PLAY mode]
2
Select the button.
≥Press 34 to select the button and
then press or .
≥Selection is also possible by
rotating or .
0 Press [DISP.] to display [Fn1] to [Fn16].
When [Setting in PLAY mode] is selected, only [Fn1] to [Fn2] are displayed.
3
Find the function to register.
≥Rotate to select the sub tab
where the function to register is
categorized (l 282, 285) and then
press or .
≥You can also select by pressing 2
to select the sub tab, pressing 34
or rotating , and then pressing 1.
≥Switch the [1] to [3] tabs by pressing [Q].
0 With default settings, [Fn8] to [Fn12] on the joystick cannot be used.
When using functions, set the [Joystick Setting] to [Fn]. (l 337)

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
