Panasonic Lumix DC-S1 User Manual

14. Menu Guide
337
[Operation] ¨ ¨
[Dial Set.]
(Continued)
[Exposure Comp.] [ ]/[ ]/`[OFF]
Assigns exposure compensation to or . (Except in
[M] mode)
0 The [Assign Dial (F/SS)] setting takes priority.
[Dial Operation
Switch Setup]
[]
[]
In the Fn button [Dial Operation Switch], this sets the items
to be assigned temporarily to or . (l 290)
[Rotation (Menu
Operation)]
`[]/[]/
[ ]/[ ]
Changes the rotational direction of the dials when operating
menus.
[Joystick Setting]
`[D.FOCUS Movement]/[Fn]/[MENU]/[OFF]
Sets the joystick movement on the recording screen.
[D.FOCUS Movement]: Moves the AF area and MF Assist.
(l 112, 117)
[Fn]: Operates as the Fn button.
[MENU]: Operates as . Operations that can be
performed by moving the joystick are disabled.
[OFF]: Disables the joystick.
[Illuminated Button]
[ON1]/`[ON2]/[OFF]
Sets the lighting timing of the illumination button.
The following illumination buttons light:
–[(] button/[Q] button/[ ] button/[ ] button/[DISP.]
button
[ON1]: Buttons are always lit while the camera is turned on.
[ON2]: Buttons are lit when [ ] is pressed. If no
operations are performed for approx. 5 seconds, this turns
off.
[OFF]: The buttons are not lit.

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
