Panasonic Lumix DC-S1 User Manual

6. Focus/Zoom
115
Moving the AF Area Position with the Touch Pad
During viewfinder display, you can touch the monitor to change the position
and size of the AF area.
1
Set [Touch Pad AF].
≥ ¨ [ ] ¨ [ ] ¨ [Touch
Settings] ¨ [Touch Pad AF] ¨
[EXACT]/[OFFSET]
2
Move the position of the AF
area.
≥During viewfinder display, touch the
monitor.
3
Change the size of the AF
area.
≥Rotate or .
0
Use for more detailed adjustments.
0 The first press of [DISP.] returns the AF
area position to the center. The second
press returns the size of the AF area to the default.
4
Confirm your selection.
≥Press the shutter button halfway.
0
For [ ], on the recording screen, press
to cancel the AF area setting.

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
