10. Flash
217
Connecting a Synchro Cable to the Flash Synchro Socket
You can use a commercially available external flash by connecting a
commercially available synchro cable to the flash synchro socket.
The socket has a lock screw to prevent the cable from falling off.
Before connecting the synchro cable to the flash synchro socket, remove
the flash synchro socket cap.
1
Rotate the flash synchro socket cap in
the direction of the arrow to remove.
0
Be careful not to lose the flash synchro
socket cap.
2
Connect the synchro cable to the flash
synchro socket.
0
For the connection, refer to the operating
instructions for the synchro cable.
0 Use an external flash with a synchronization voltage of 400 V or less.
0 Do not use the synchro cables with the length of 3 m (9.8 feet) or more.
0 The flash synchro socket has no polarity. You can use a synchro cable
regardless of its polarity.
