Panasonic Lumix DC-S1 User Manual

6. Focus/Zoom
106

Move and Change the Size of the AF Area
1
Press [ ] to display the AF mode selection screen.
2
Select [ ], [ ] or [ ] and then press 4.
3
Press 3421 to move the position of
the AF area.
0
You can also move the AF area by
touching.
≥When [ ] is selected
– Press 34 to switch to a horizontal
pattern AF area.
– Press 21 to switch to a vertical pattern AF area.
≥When [ ]/[ ] are selected
– Positions can be moved to the diagonal directions using the joystick.
4
Rotate or to change the size of the AF area.
0
You can also pinch out/pinch in the AF area to change the size.
0 The first press of [DISP.] returns the AF area position to the center. The second
press returns the size of the AF area to the default.
5
Press .
0 The display method for the AF area using 225-area focusing can be changed:
[] ¨ [ ] ¨ [AF Area Display] (l 341)

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
