Panasonic Lumix DC-S1 User Manual

6. Focus/Zoom
109

Move the Position of the AF Area
1
Press [ ] to display the AF mode selection screen.
2
Select [ ] and then press 4.
3
Press 3421 to set the position of [i] and then press or .
0
Positions can be moved to the diagonal directions using the joystick.
0 The selected position on the screen will be enlarged.
0 The AF area cannot be moved to the edge of the screen.
4
Press 3421 to fine-adjust the
position of [i].
5
Press or .
Operations on the Magnification Window
Button
operation
Touch
operation
Description of operation
3421 Touch
Moves [i].
0 Positions can be moved to the diagonal
directions using the joystick.
Pinch out/
pinch in
Enlarges/reduces the screen in small steps.
s Enlarges/reduces the screen.
Switches magnification window (windowed
mode/full screen mode).
[DISP.] [Reset]
First time: Returns to the screen in Step
3
.
Second time: Returns the AF area position to
the center.

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
