11. Recording Videos
251
4
Fit the USB connection cable (C–C or
A–C) (F) and HDMI cable (G) to the
clamp.
5
Slide the clamp portion (H) to attach it
to the cable holder.
6
Connect the USB connection cable
(C–C or A–C) to the USB port (I).
7
Connect the HDMI cable to the [HDMI]
socket (J).
K Leave some slack so that this section
has a length of at least 10 cm (0.33 feet).
Removing the cable holder
To remove the cable holder, follow the steps for attaching it in the reverse
order.
0 Do not use any other USB connection cables except the supplied USB
connection cables (C–C and A–C).
0 We recommend using an HDMI cable with a thickness diameter of 6.5 mm
(0.26 inch) or less.
0 It may not be possible to attach HDMI cables of certain shapes.

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
