Panasonic Lumix DC-S1 User Manual

11. Recording Videos
256

Reduction of Wind Noise
This reduces wind noise when an external microphone is connected.
¨ [ ] ¨ [ ] ¨ Select [Wind Cut]
Settings: [HIGH]/[STANDARD]/[LOW]/[OFF]
0 You can register a function with the Fn button:
[] ¨ [ ] ¨ [Fn Button Set] ¨ [Setting in REC mode] ¨ [Mic. Directivity
Adjust] (l 279)
0 While the external microphone is connected, [ ] is displayed on the screen.
0 When an external microphone is connected, [Sound Rec Level Disp.]
automatically turns [ON], and the recording level is displayed on the screen.
0 When the external microphone is attached, do not carry the camera by holding
the external microphone. It may become detached.
0 If noises are recorded when using the AC adaptor, use the battery.
0 When [Special Mic.] is set to [LENS AUTO], [S. SHOTGUN] or [MANUAL],
[Sound Output] is fixed to [REC SOUND].
0 When a Stereo Microphone (VW-VMS10: optional) is used, [Special Mic.] is
fixed to [STEREO].
0 Setting [Wind Cut] may alter the usual sound quality.
0 For details, refer to the operating instructions for the external microphone.

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
