Panasonic Lumix DC-S1 User Manual

14. Menu Guide
343
[Monitor / Display] ¨ ¨
[Night Mode]
[Monitor] [ON]/`[OFF]
[LVF] [ON]/`[OFF]
Displays monitor and viewfinder in red.
In dark environments, this reduces brightness of the screen
that can make the surroundings difficult to see.
You can also set the luminance of the red display.
1 Press 3421 to select [ON] on the monitor or
viewfinder (LVF).
2 Press [DISP.] to display the brightness adjustment
screen.
0 Display the monitor to adjust the monitor, and display
the viewfinder to adjust the viewfinder.
3 Press 21 to adjust luminance and then press or
.
0 This effect is not applied to images output via HDMI.
0 This menu item can be registered to the Fn button.
(l 279)
[LVF/Monitor Disp.
Set]
[LVF Disp. Set] []/`[]
[Monitor Disp. Set] []/`[]
You can select whether to display the live view in full screen
or to avoid covering the information display.
[]: Scales down images slightly so
that you can better review the composition
of the images.
[]: Scales images to fill the entire
screen so that you can see their details.
999
±
0
AFSAFS
L
FINE
AFSAFS
999
±
0
L
FINE

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
