Panasonic Lumix DC-S1 User Manual

17. Materials
473
Removing dirt on the image sensor
The image sensor is very precise and delicate, so be sure to observe the
following when you do have to clean it yourself.
0
Blow dust off the surface of the image sensor using a commercially available blower.
Do not blow the dust off with excessive power.
0 Do not put the blower brush further inside than the lens mount.
0 Do not let the blower brush touch the image sensor as the image sensor may get
scratched.
0 Do not use any objects except a blower brush to clean the image sensor.
0 If you cannot remove the dirt or dust with the blower, consult the dealer or
Panasonic.

Cleaning the Viewfinder
If the viewfinder is dirty, then remove
the eye cup and clean.
While pushing the eye cup lock lever
(1), rotate the eye cup in the
direction of the arrow and remove
(2).
Blow dirt off the surface of the
viewfinder using a commercially
available blower, then lightly wipe
with a soft, dry cloth.
0
After cleaning, align the fitting marks (#)
3 and rotate the eye cup in the direction
of the arrow until a click is heard (4).
0 Be careful not to lose the eye cup.
 




Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
