Panasonic Lumix DC-S1 User Manual

6. Focus/Zoom
95
On the recording screen, press and hold
[Fn1].
0
Part of the screen is displayed enlarged while
[Fn1] is pressed and held.
0 When the screen is enlarged, pressing the
shutter button halfway re-acquires focus in a
small central AF area.
0 When the screen is enlarged, turn or
to adjust the magnification.
Use for more detailed adjustments.
0 If the camera temperature rises under any of the following conditions, [ ]
may be displayed and use of AF Point Scope may not be possible.
Wait until the camera cools down.
– During continuous usage of AF Point Scope
– When the ambient temperature is high
0 When the screen is enlarged, [AFC] changes to [AFS].
0 When the following functions are being used, AF Point Scope cannot be used:
– Video recording/[6K/4K PHOTO]/[Post-Focus]
– [65:24]/[2:1] ([Aspect Ratio])
– [Miniature Effect] ([Filter Settings])
– [Multiple Exposure]
0 You can change the display method of the magnified screen:
[] ¨ [ ] ¨ [AF-Point Scope Setting] (l 332)

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
