ENGLISH - 59
Items Operation Adjustment
[H]
Press the q button.
Left side will be smaller.
Press the w button.
Right side will be smaller.
[V]
Press the a button.
Upper will be smaller.
Press the s button.
Lower will be smaller.
Note
f Pressing the <ENTER> button while the individual adjustment screen is displayed can switch to the individual adjustment screen of other
items.
f For the adjustments of [KEYSTONE], up to ±15° tilt in the horizontal and vertical direction can be corrected. However, the image quality will
degrade and it will get harder to focus as the correction increases. Install the projector so that the correction will be as small as possible.
Setting [CORNER CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [CORNER CORRECTION].
4) Press the <ENTER> button.
f The [CORNER CORRECTION] screen is displayed.
5) Press as to select the item to adjust. Then press the <ENTER> button.
f The individual adjustment screen of the selected item is displayed.
6) Press asqw to adjust.
[CORNER CORRECTION]
[UPPER LEFT] [UPPER RIGHT] [LOWER LEFT] [LOWER RIGHT]
Note
f When the [CORNER CORRECTION] individual adjustment screen is displaying, the individual adjustment screen of the next corner can also
be displayed by pressing the <ENTER> button.
f Depending on the correction amount, the image aspect ratio may change.
Setting [CURVED CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [CURVED CORRECTION].
Chapter 4 Settings - [POSITION] menu
