8 Self diagnosis and special mode setting
This unit is equipped with features of self-diagnostic & special mode setting for checking the functions & reliability.
8.1. Service Mode Summary Table
The service modes can be activated by pressing various button combination on the main unit and remote control unit.Below is the
summary for the various modes for checking:
Player buttons Remote control unit buttons Application Note
[STOP] [4], [7] To Enter into Doctor Mode for various checking (Refer to the section “8.2. for more information.)
Player buttons Remote control unit buttons Application Note
Note :
Applicable in
Doctor Mode
[DIMMER] FL ALL Segment inspection (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
[7] Forced VOL setting (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
[8] Forced VOL setting (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
[9] Forced VOL setting (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
[ ], [1], [2] CR 100 Traverse Test (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
[ ], [1], [4] CD Auto Adjustment Display (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
[SLEEP] Cold Start Setting (Refer to the section “8.2. service mode Table 1
& Table 2 for more information.)
13
SA-PM4E / SA-PM4EB / SA-PM4EG
