Notes:
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0097 17P FFC (MAIN-CD) [M]
4 RGLV0061-Q LIGHTING TIP [M]
5 RFKHAPM4EB-S REAR CABINET ASS’Y [M]EB
5 RKSV0033E-H REAR CABINET [M]EG E
6 RFKGAPM4EG-S FRONT CABINET ASS’Y [M]
7 RGUV0134D-S FUNCTION BUTTON [M]
8 RGUV0136A-S1 POWER BUTTON [M]
9 RGUV0139A-S1 CONTROL BUTTON [M]
10 RGWV0039-2S1 VOLUME KNOB [M]
11 RHD26046-L SCREW [M]
12 RHD30111-3 SCREW [M]
13 RKA0072-KJ LEG CUSHION [M]
14 RKFV0054A-S1 CD LID [M]
15 RKMV0055A-H1 SIDE PANEL L [M]
16 RKMV0056A-H1 SIDE PANEL R [M]
17 RKMV0057B-H2 TOP CABINET [M]
18 RMBV0041 CD LID OPEN SPRING [M]
19 RMF0188-1L CLAMPER SHEET [M]
20 RMGV0032 RUBBER SPACER [M]
21 RMKV0045-1 BOTTOM CHASSIS [M]
22 RMNV0062 FL HOLDER [M]
23 RMNV0084 ANT HOLDER [M]
24 RMQ0152-E FIXTURE [M]
25 RMQ0496-K CD CLAMPER [M]
26 RMQX0058 SPACER [M]
27 RMYV0070 HEAT SINK [M]
28 RSC0733J TUNER SHIELD [M]
30 RWJ1104120QX 4P WIRE (PANEL-TRAN) [M]
31 RWJ1107110QX 7P WIRE [M]
32 RWJ1111120QX 11P WIRE (PANEL TO MAIN) [M]
33 RXGX0002 DAMPER GEAR [M]
34 XTB3+10JFJ SCREW [M]
35 XTV3+12GFJ-M SCREW [M]
Ref.
No.
Part No. Part Name & Description Remarks
36 XTV3+8FFJ SCREW [M]
37 RHM0001 MAGNET [M]
38 RSCV0067 REAR SHIELD [M]
39 RSC0669 SPEAKER JACK SHIELD [M]
TRAVERSE DECK
358 RAE0165A-V TRV UNIT WITHOUT SERVO [M]
359 RME0109-1 FLOATING SPRING [M]
360 RMG0703-R FLOATING RUBBER [M]
361 RMR1396-K TRAVERSE COVER [M]
362 RMR1395-X MIDDLE CHASSIS [M]
363 RMS0757-1 FIXED PIN [M]
364 XTN2+6GFJ SCREW [M]
Printed Circuit Board
REPV0082A CD SERVO P.C.B [M] RTL
REPV0123A TRANSFOMRER P.C.B / MAIN
P.C.B / PANEL P.C.B / CD
EJECT P.C.B / HP/MUSIC PORT
P.C.B
[M] RTL
INTEGRATED CIRCUITS
IC1 C1BB00001120 IC TUNER [M]
IC300 AN17831A IC POWER AMP [M]
IC301 C1BB00000732 IC ASP [M]
IC302 LC72725K-M IC RDS [M]
IC650 C0DAZYY00016 IC 9V REGULATOR [M]
IC651 C0DBZGC00067 IC 3.3V REGULATOR [M]
IC652 C0CAABC00007 IC 3.3V REGULATOR [M]
IC700 C0ABBB000297 IC DUAL OP-AMP [M]
IC800 MN101EF16ZXW IC MICROPROCESSOR [M]
IC801 C0CAABC00007 IC 3.3V REGULATOR [M]
20 Replacement Parts List
·
Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthe rmore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
·
The parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
·
Warning: This product uses a laser diode. Refer to “Precaution of Laser Diode”.
ACTUNG:
Die Lasereinheit nicht zerlegen.
Die Lasereinheit darf nur gegen eine vom Hertsteller spezifizierte Einheit ausgetauscht werden.
·
Capacitor values are in microfarads (µF) unless specified otherwise, P= Pico-farads (pF), F= Farads.
·
Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
·
T he marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
·
[M] Indicates in the Remarks columns indicates parts supplied by PAVCSG.
·
Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp: Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian Ur: Ukraine
63
SA-PM4E / SA-PM4EB / SA-PM4EG
