Panasonic SA-PM4E - Page 64

Ref.
No.
Part No. Part Name & Description Remarks
IC802 C0EBE0000455 IC VOLTAGE REGULATOR [M]
IC900 C0HBB0000057 IC FL DRIVER [M]
IC7001 MN6627954MA IC SERVO PROCESSOR/DIGITAL
SIGNAL PROCESSOR/DIGITAL
FILTER D/A CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Q1 B1ABDF000026 TRANSISTOR [M]
Q2 B1ADCF000063 TRANSISTOR [M]
Q221 B1ABGC000001 TRANSISTOR [M]
Q222 B1ABGC000001 TRANSISTOR [M]
Q300 B1GDCFGG0026 TRANSISTOR [M]
Q301 B1GBCFJJ0044 TRANSISTOR [M]
Q302 B1GBCFJJ0044 TRANSISTOR [M]
Q303 B1ADCF000063 TRANSISTOR [M]
Q421 B1ABGC000001 TRANSISTOR [M]
Q422 B1ABGC000001 TRANSISTOR [M]
Q601 2SB0621AHA TRANSISTOR [M]
Q651 B1AAJC000019 TRANSISTOR [M]
Q652 B1AAJC000019 TRANSISTOR [M]
Q653 2SD1819A0L TRANSISTOR [M]
Q800 B1AAJC000019 TRANSISTOR [M]
Q802 2SD1819A0L TRANSISTOR [M]
Q803 2SD1819A0L TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
DIODES
D1 B0CDAD000010 DIODE [M]
D2 B0CDAB000019 DIODE [M]
D3 B0CDAB000019 DIODE [M]
D4 B0AACK000004 DIODE [M]
D300 B0ACCK000005 DIODE [M]
D601 B0EAMM000038 DIODE [M]
D602 B0EAMM000038 DIODE [M]
D603 B0EAMM000038 DIODE [M]
D604 B0EAMM000038 DIODE [M]
D605 B0EAKM000117 DIODE [M]
D606 B0BC02900004 DIODE [M]
D607 B0EAKM000117 DIODE [M]
D650 B0BC8R100004 DIODE [M]
D651 B0BC5R600003 DIODE [M]
D652 B0ADCJ000020 DIODE [M]
D653 B0EAKM000117 DIODE [M]
D656 B0EAKM000117 DIODE [M]
D657 B0EAKM000117 DIODE [M]
D751 B0ACEL000004 DIODE [M]
D800 B0ACCK000005 DIODE [M]
D801 B0ACCK000005 DIODE [M]
D802 B0ACCK000005 DIODE [M]
D803 B0BC4R600016 DIODE [M]
D804 B0BC01000014 DIODE [M]
D900 B0BC6R700006 DIODE [M]
D901 B3AAA0000487 DIODE [M]
D7650 MAZ80560ML DIODE [M]
VARIABLE RESISTORS
VR900 EVEJ1CF3024B VOLUME JOG [M]
SWITCHES
S900 EVQ21405RJ SW POWER [M]
S901 EVQ21405RJ SW BASS/TREBLE [M]
S902 EVQ21405RJ SW /FF/ [M]
S903 EVQ21405RJ SW /REW/ [M]
S904 EVQ21405RJ SW MUSIC PORT [M]
S905 EVQ21405RJ SW STOP/-DEMO [M]
S906 EVQ21405RJ SW TUNER [M]
S907 EVQ21405RJ SW CD [M]
S1000 RSP1A026-Q SW CD EJECT [M]
Ref.
No.
Part No. Part Name & Description Remarks
S7201 RSH1A048-A SW RESET [M]
CONNECTORS
CN301 K1MN17A00040 17P FFC CONNECTOR [M]
CN450 K1MP07A00011 7P CONNECTOR [M]
CN451 K1MP11A00004 11P CONNECTOR [M]
CN650 K1KA03AA0180 MOTOR CONNECTOR [M]
CN800 K1MN06A00013 6P FFC CONNECTOR [M]
CN900 RMR0320 11P WIRE HOLDER [M]
CN900B K1MP04A00003 4P CONNECTOR [M]
CN7001 K1MN16B00154 16P CONNECTOR [M]
CN7002 K1MN17B00032 17P CONNECTOR [M]
CP800 K1KA02AA0180 MOTOR CONNECTOR [M]
P1 K1KA03BA0125 CONNECTOR [M]
COILS & TRANSFORMERS
L1 G0ZZ00002353 FM COIL [M]
L3 G0ZZ00002353 FM COIL [M]
L5 G0ZZ00002453 FM OSC COIL [M]
L7 G2BPC0000017 AM OSC COIL [M]
L8 G0C101KA0029 AXIAL COIL [M]
L51 G2A390C00001 AM RF-COIL [M]
L600 G0B371HA0005 LINE FILTER [M]
L800 G0C3R3JA0027 COIL [M]
L801 G0C3R3JA0027 COIL [M]
L900 G0C3R3JA0027 COIL [M]
L901 G0C101JA0027 COIL [M]
L950 J0JBC0000019 CHIP INDUCTOR [M]
LB321 J0JBC0000015 CHIP INDUCTOR [M]
T1 G2BAC0000053 AM IF COIL [M]
T601 G4CYAYY00142 TRANSFORMER [M]
COMPONENT COMBINATION
Z900 B3RAD0000128 REMOTE SENSOR [M]
IP800 K5G251A00008 FUSE PROTECTOR [M]
CERAMIC FILTERS
CF1 J0B1075A0129 CERAMIC FILTER [M]
OSCILLATORS
X1 J0B1075A0121 CERAMIC FILTER [M]
X2 H0A750200020 CRYSTAL [M]
X320 H0H433400002 CRYSTAL [M]
X801 H4Z8004AA001 CERAMIC RESONATOR [M]
X802 H0A327200100 CRYSTAL [M]
X7201 H2B169500005 CRYSTAL [M]
DISPLAY TUBE
FL900 A2BB00000166 FL DISPLAY [M]
FUSE
F1 K5D631BLA012 FUSE [M]
FUSE HOLDERS
FC600 EYF52BCY FUSE CLIP [M]
FC601 EYF52BCY FUSE CLIP [M]
FUSE PROTECTOR
FP300 K5G502A00039 FUSE PROTECTOR [M]
JACKS
64
SA-PM4E / SA-PM4EB / SA-PM4EG
