Pin No. Mark I/O Function
81 N.C. - No Connection
82 N.C. - No Connection
83 N.C. - No Connection
84 N.C. - No Connection
85 CD_OPEN
_SW
I/O CD Open SW (H:Open;
L:Close)
86 REST_SW I/O REST SW (L: inner)
87 N.C. - No Connection
88 N.C. - No Connection
89 VDD - Micom VDD +5V
90 N.C. - No Connection
91 VSS - Ground Connection
92 KEY1 I Key 1 Input
93 KEY2 I Key 2 Input
94 N.C. - No Connection
95 N.C. - No Connection
96 DCDET I DC Level Detection Input
97 REGION I Region Setting Input
98 N.C. - No Connection
99 N.C. - No Connection
100 VREF + - A/D Converter reference voltage
+3.3V
