Panasonic SC-DP1 User Manual

15
RQT6815
Disc operations
Discs—Convenient functions
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3] [JPEG]
Press the numbered buttons to select the
item.
Play starts from the selected item.
To select a 2-digit number
Example: To select track 23, press [S10] ➡ [2] ➡ [3].
[WMA] [MP3] [JPEG]: [2] ➡ [3] ➡ [ENTER]
[Note\
This works only when stopped with some discs.
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3] [JPEG]
During play
Press [REPEAT].
Each time you press the button:
[RAM]
Program>All (Entire disc)>Off
≥During play list play
Scene>Playlist>Off
[DVD-V]
Chapter>Title
§
>Off
[VCD] [CD]
Tr ack >All (Entire disc)>Off
[DVD-A] [WMA] [MP3]
Tr ack >Group
§
>Off
[JPEG]
Group>Off
§During all group ([DVD-A]), program and random play
“All” is displayed.
≥You can also repeat play of content and group on HighMAT discs.
∫ To repeat only your favorite tracks/chapters
[DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]
Start program play ( ➡page 16) and press [REPEAT] to select the
repeat mode.
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]
You can repeat a section between points A and B within a program,
title or track.
1 During play
Press [GUI DISP] until the unit
information screen is displayed
(➡ page 24).
2 Press [3, 4] to select the play menu.
3 Press [ 2 , 1 ] to select “A-B Repeat” and
1 Press [ENTER] at the starting point
(A).
2 Press [ENTER] at the finishing
point (B).
A-B repeat starts.
To return to the normal play
Press [ENTER] again.
To clear the menus
Press [RETURN] until the menu disappears.
[Note]
≥Subtitles recorded around A and B may fail to appear.
≥The end of an item becomes point B when it is reached.
≥A-B repeat is canceled when you press [QUICK REPLAY].
[DVD-A] [WMA] [MP3] [JPEG]
1 Press [SHIFT]r[GROUP].
2 Press the numbered buttons to select
the group and press [ENTER].
3 Press the numbered buttons to select
the track/picture number and press
[ENTER].
[DVD-A]
Playing all the groups in succession (➡ page 16, All group play)
Playing bonus groups
Some discs contain bonus groups. If a password screen appears
after selecting a group, enter the password with the numbered
buttons. Refer also to the disc’s jacket.
Starting play from a selected item
Repeat play
TVÍ
TV/VIDEO
SETUP
PROGRAM
132
465
798
0
S 10
REPEAT
AUDIO
TU
N
E
R
/A
U
X
D
IR
E
C
T
NAVIGATOR
TOP MENU
PLAY LIST
M
ENU
CANCEL
MUTING VOLUME
SUBTITLE
PLAY MODE
CLOCK/
TIMER
SLEEP
F PLAY
Í
P.MEMORY
TV VOL
r
TV VOLs
PAG E
ENTER
GUI DISP
DISPLAY
QUICK REPLAY ZOOM
SHIFT
SURROUND
CINEMA D.ENH SUBWOOFER
SOUND
SLOW/SEARCH
ANGLE
RETURN
TV
CH
X
TV
CH
W
X SKIP W
GROUP
DVD/CD
132
465
798
0
S 10
ENTER
REPEAT
GUI DISP
SHIFT
RETURN
GROUP
ENTER
DOUBLE
RE-MASTER
Numbered
buttons
A-B repeat play
Selecting groups to play
A-B Repeat
Example: [DVD-V]
A-B
Example: [MP3]
Group number
Track number in group

Panasonic SC-DP1 Specifications

Amplifier Specifications

RMS Output Power (Low-channel)	25 W per channel (6 ≠)
RMS Output Power (High-channel)	25 W per channel (6 ≠)
Total Bi-Amp power	50 W per channel
Total RMS Stereo mode power	100 W
Total RMS Dolby Digital mode power	100 W
PMPO Output Power	1000 W
DIN Output Power (Low-channel)	20 W per channel (6 ≠)
DIN Output Power (High-channel)	20 W per channel (6 ≠)
Total DIN Power in Stereo mode	80 W
Total DIN Power in Dolby Digital mode	80 W
AUX Input sensitivity	250 mV
AUX Input impedance	19 k≠

FM Tuner Specifications

Frequency range	87.50–108.00 MHz (50-kHz step)
Sensitivity	2.5 µV (IHF)
S/N 26 dB	2.2 µV
Antenna terminals	75 ≠ (unbalanced)
Preset station	15

AM Tuner Specifications

Frequency range (UK, Europe, Russia)	522–1629 kHz (9-kHz steps)
Frequency range (Australia, N.Z., Southeast Asia)	522–1629 kHz (9-kHz steps)/520–1630 kHz (10-kHz steps)
Sensitivity	560 µV/m
Preset station	15

Speaker Specifications

Type	2 way, 2 speaker system
Tweeter	6 cm cone type 6 ≠
Woofer	10 cm cone type 6 ≠
Input power (High)	50 W (Music)
Input power (Low)	50 W (Music)
Output sound pressure level	81 dB/W (1.0 m)
Crossover frequency	2.2 kHz
Frequency range (16 dB)	47 Hz–32 kHz
Frequency range (10 dB)	64 Hz–31 kHz
Dimensions (WxHxD)	158k276k280 mm
Mass	2.4 kg

General Specifications

Power supply (UK, Australia, N.Z.)	AC 230–240 V, 50 Hz
Power supply (Europe, Russia)	AC 230 V, 50 Hz
Power supply (Southeast Asia except Thailand)	AC 230–240 V, 50/60 Hz
Power supply (Thailand)	AC 220 V, 50 Hz
Power consumption	105 W
Dimensions (WxHxD)	205k123.5k383.5 mm
Mass	4.2 kg
Power consumption in standby mode	1 W
