28
RQT6815
Other functions
Convenient functions
Preparation
≥Connect an active subwoofer (not included). See below for
connection.
≥Place the subwoofer as close as possible to the front center.
[Adjusting\the\bass]
Press [SHIFT]r[SUBWOOFER].
Each time you press the buttons:
SUB W LOW (factory preset)>SUB W MID>SUB W MAX
^----------------------------------------------------------------------------------}
Adjust the volume on the subwoofer to suit your preference.
[Note]
When using headphones, the subwoofer should be switched off.
Press [MUTING].
Volume is reduced to minimum.
To cancel
Press [MUTING] again or reduce the volume to minimum (–– dB),
then raise it to the required level.
Muting is also canceled when you switch the unit to standby.
You can display the time or dim the display.
Press [SHIFT]r[DISPLAY] until the display
you want appears.
Each time you press the buttons:
A) Clock (The time appears.)
lv
l Dimmer On (The display dims.)
lv
{=Dimmer Off (Original display)
[Note]
The original display is restored when you:
—Turn the unit off.
—Select another source.
Face the remote control at the television for the following operations.
Turning the television on/off
Press [SHIFT]r[TVÍ].
Switching the television’s video input mode
Press [SHIFT]r[TV/VIDEO].
Changing channels
Press [SHIFT]r[TV CHX] or [SHIFT]r[TV CHW].
Adjusting the volume
Press [SHIFT]r[TV VOLr] or [SHIFT]r[TV VOLs].
[Note]
Some models cannot be operated by this remote control.
Enjoying more powerful bass
TVÍ
TV/VIDEO
SETUP
PROGRAM
132
465
798
0
S 10
REPEAT
AUDIO
T
U
N
E
R
/A
U
X
D
IR
E
C
T
NAVIGATOR
TOP MENU
PLAY LIST
M
EN
U
CANCEL
MUTING VOLUME
SUBTITLE
PLAY MODE
CLOCK/
TIMER
SLEEP
F PLAY
Í
P.MEMORY
TV VOL
r
TV VOL s
PAG E
ENTER
GUI DISP
DISPLAY
QUICK REPLAY ZOOM
SHIFT
SURROUND
CINEMA D.ENH SUBWOOFER
SOUND
SLOW/SEARCH
ANGLE
RETURN
TV
CH
X
TV
CH
W
X SKIP W
GROUP
DVD/CD
ENTER
MUTING
TV/VIDEO
TV
SHIFT
DISPLAY
SLEEP
PLAY
CLOCK/TIMER
VOLUME
TV VOL
TV VOL
SUBWOOFER
X
W
W
SKIP
X
TV CH
TV CH
F
Í
Í
ENTER
DOUBLE
RE-MASTER
AM ANT
COMPONENT VIDEO OUT
P
R
P
Y
B
EXT
OPTICAL
OUT
S-VIDEO
R
R
L
L
--
AUX
SUBWOOFER
OUT
OUT
VIDEO
OUT
LOOP
75≠
HIGH (6≠)
SPEAKERS (
LO
FM ANT
SUBWOOFER
OUT
Audio cable
(not included)
To the
subwoofer’s
input terminal
SUB W MID
Muting the volume
Changing the display
Operating a television
MUTING

Panasonic SC-DP1 Specifications

Amplifier Specifications

RMS Output Power (Low-channel)	25 W per channel (6 ≠)
RMS Output Power (High-channel)	25 W per channel (6 ≠)
Total Bi-Amp power	50 W per channel
Total RMS Stereo mode power	100 W
Total RMS Dolby Digital mode power	100 W
PMPO Output Power	1000 W
DIN Output Power (Low-channel)	20 W per channel (6 ≠)
DIN Output Power (High-channel)	20 W per channel (6 ≠)
Total DIN Power in Stereo mode	80 W
Total DIN Power in Dolby Digital mode	80 W
AUX Input sensitivity	250 mV
AUX Input impedance	19 k≠

FM Tuner Specifications

Frequency range	87.50–108.00 MHz (50-kHz step)
Sensitivity	2.5 µV (IHF)
S/N 26 dB	2.2 µV
Antenna terminals	75 ≠ (unbalanced)
Preset station	15

AM Tuner Specifications

Frequency range (UK, Europe, Russia)	522–1629 kHz (9-kHz steps)
Frequency range (Australia, N.Z., Southeast Asia)	522–1629 kHz (9-kHz steps)/520–1630 kHz (10-kHz steps)
Sensitivity	560 µV/m
Preset station	15

Speaker Specifications

Type	2 way, 2 speaker system
Tweeter	6 cm cone type 6 ≠
Woofer	10 cm cone type 6 ≠
Input power (High)	50 W (Music)
Input power (Low)	50 W (Music)
Output sound pressure level	81 dB/W (1.0 m)
Crossover frequency	2.2 kHz
Frequency range (16 dB)	47 Hz–32 kHz
Frequency range (10 dB)	64 Hz–31 kHz
Dimensions (WxHxD)	158k276k280 mm
Mass	2.4 kg

General Specifications

Power supply (UK, Australia, N.Z.)	AC 230–240 V, 50 Hz
Power supply (Europe, Russia)	AC 230 V, 50 Hz
Power supply (Southeast Asia except Thailand)	AC 230–240 V, 50/60 Hz
Power supply (Thailand)	AC 220 V, 50 Hz
Power consumption	105 W
Dimensions (WxHxD)	205k123.5k383.5 mm
Mass	4.2 kg
Power consumption in standby mode	1 W
